Photovoltaic system: Full analysis of combiner box
2025-05-05
The stable operation of photovoltaic power generation system is inseparable from a seemingly inconspicuous but crucial device - combiner box. It is the "bridge" between photovoltaic array and inverter, and undertakes multiple functions such as current collection, safety protection, and intelligent monitoring. Bonada will take you to understand the operating principle and technological development of combiner box.
1. What is combiner box?
The combiner box is the core wiring device in the photovoltaic power generation system. It is mainly used to connect the DC current of multiple photovoltaic strings (composed of panels of the same specifications connected in series) in parallel, and transmit it to the inverter after processing by protection components, and finally achieve grid connection with the grid.
·Core function: reduce the complex connection between photovoltaic components and inverters, simplify the system structure, and improve maintenance efficiency.
·Safety value: when the local component fails, the problem branch can be quickly isolated to avoid the shutdown of the entire system and reduce the risks of lightning strikes and overcurrent.
2. Three functional modules of the combiner box
Current collection and transmission
Supports 6-24 photovoltaic string inputs, with a single current of usually 10-20A, which is output to the inverter after being combined through the copper busbar.
Anti-reverse diodes are used to prevent current reverse flow and avoid energy backflow due to shielding or failure of components.
Multiple safety protections
·Overcurrent protection: DC fuses (breaking capacity up to 20kA) can cut off the fault branch within 0.1 seconds in the event of a short circuit.
·Lightning protection design: T1-level composite lightning arrester (response time <25 nanoseconds) can discharge lightning energy and reduce the lightning strike failure rate by 83%.
·Insulation monitoring: Unbalanced bridge technology detects ground impedance in real time (sensitivity ≤500kΩ) and warns of leakage hazards.
Intelligent monitoring and operation and maintenance
Monitor each current and voltage through Hall sensors with an accuracy of ±1%, and support RS485 or wireless communication for remote data transmission.
The third-generation intelligent combiner box has added functions such as temperature sensors, fault alarms, and wireless data transmission to achieve preventive maintenance.
